Description
Engineered for safe, efficient illumination in hazardous environments, the Tegralux BYS Series Explosion-Proof Linear Light delivers reliable performance for industrial applications. Powered by advanced OSRAM German technology, it ensures high efficiency and long service life. Certified to ATEX standards, the BYS Series is suitable for Zone 1 and Zone 2 areas, and built with rugged IP66 protection against dust and water ingress for dependable operation in demanding conditions.
Features:
- Zone 1&2, Zone 21&22
- GRP enclosure, corrosion-proof, PC lampshade, stripshaped, anti-glare
- Built-in explosion proof interlock device, automatically power-off after cover open
- Lamp adopt curve sealed structure, high waterproof and dust proof class
- Lightweight and slim line construction
- The emergency device can be equipped at the request of users
Specification
| Type | BYS-600 | BYS-1200 |
|---|---|---|
| European (ATEX) | II 2G Ex de IIC T6 | II 2G Ex de IIC T6 |
| Input voltage | 220VAC,50-60Hz | 220VAC,50-60Hz |
| T8 Fluorescent tube | (1~3)*18Watt | (1~3)*36Watt |
| LED tube | (1~3)*8Watt | (1~3)*8Watt |
| Degree of protection | IP66 | IP66 |
| Size | L798* W208*H120 | L1380* W208*H120 |
| Mounting Styles | Pendant; Ceiling; Wall; Stanchion | Pendant; Ceiling; Wall; Stanchion |
